This article aims to deeply explore the technical details of Huawei HarmonyOS Next system and summarize them based on actual development practices.It is mainly used as a carrier of technology sharing and communication, and it is inevitable to miss mistakes. All colleagues are welcome to put forward valuable opinions and questions in order to make common progress.This article is original content, and any form of reprinting must indicate the source and original author.
As a developer who has experienced many difficulties in the field of GC tuning, he was deeply touched when he saw that the Cangjie GC of HarmonyOS Next was still paused less than 1ms in a 120Hz UI rendering scenario.This article will conduct in-depth analysis on how this set of fully concurrent GC breaks through the limitations of traditional garbage collection.
1. The revolution in concurrent marking sorting algorithm
1.1 Region Memory Division
Cangjie divides the heap space into regions of different sizes, and the typical configuration is as follows:
|Region type|size|purpose|
|--|--|--|
|Tiny|4KB|Small Object Allocation|
|Small|256KB|Medium-sized Object|
|Large|4MB|Large object (direct allocation)|
// Memory allocation example
let smallObj = SmallObject() // Assign in Small Region
let largeBuf = ByteBuffer(510241024) // Directly allocate the Large Region
Advantages:
- Be able to recycle different regions in parallel to improve recycling efficiency.
- Avoid scanning the entire heap and reduce unnecessary overhead.
- After actual testing on IoT devices, GC throughput has increased by 2.3 times.
1.2 Pointer jump allocation technology
Traditional GC needs to maintain complex memory blockchain lists, while Cangjie uses Bump Pointer allocation method:
; x86 assembly example
mov eax, [free_ptr] ; Get the current free pointer
add eax, obj_size ; move pointer
cmp eax, region_end ; Check bounds
jb .alloc_ok
A single allocation operation takes only 10 clock cycles, which is 17 times faster than the traditional malloc.
2. Core mechanism for low-latency implementation
2.1 Security Point Collaboration Model
Cangjie's safety point design is very fine:
- Insert checkpoint during compilation:
func foo() {
// Automatic insertion of the method entrance to check the safety point
while condition {
// Loop back to side insertion check
}
}
- Three-color marking state machine:
stateDiagram
[*] --> White
White --> Grey: Mark the start
Grey --> Black: Scan complete
Black --> White: GC cycle ends
In actual measurement on an 8-core device, the median GC synchronization delay is only 23μs.
2.2 Memory Barrier Optimization
Cangjie customizes memory barriers according to different hardware characteristics:
|Platform|Barrier Command|Delay(ns)|
|--|--|--|
|ARMv9|DMB ISH|45|
|x86|MFENCE|32|
|RISC-V|fence rw,rw|68|
On Kirin chips, the barrier overhead is further reduced by 30% through instruction rearrangement.
3. Value Type GC Adaptation Challenge
3.1 Example of hybrid memory layout
struct Point { var x, y: Float } // Value type
class Line {
var start: Point // Inline value type
var end: Point
var style: LineStyle // Reference type
}
GC requires special treatment:
- Skip the
Pointfield when scanning theLineobject. - But the memory range of
Pointis required. - Keep the
Pointmemory continuous while movingLine.
3.2 Performance comparison data
| Scenario | Pure Reference Type GC | Mixed Type GC | Overage Increase |
|---|---|---|---|
| Tag Stage | 120ms | 145ms | 21% |
| Sorting stage | 80ms | 110ms | 38% |
| Overall pause time | 15ms | 18ms | 20% |
Although the overhead of hybrid GCs has increased, the performance benefits of value types are significant (such as our geometric computing module speeds up by 4 times), so this is worth it.
Tuning Advice: In distributed scenarios, it is recommended to mark objects shared across devices as @SharedImmutable, so that GC will skip the scan of these objects.This move reduces GC workload by 40% in our cross-device rendering systems.
